Week 4: Services and Actions
Service Client-Server Pattern
While topics enable continuous data streaming, many robot operations require request-response interactions. Services provide synchronous RPC (Remote Procedure Call) semantics: a client sends a request and blocks until receiving a response from the server.
When to Use Services
Services are ideal for:
- Infrequent queries: Computing inverse kinematics for a target pose
- Configuration changes: Setting controller gains or switching operational modes
- State queries: Requesting current battery level or system diagnostics
- Atomic operations: Triggering calibration sequences that must complete before returning
Critical distinction: Services block the calling node until complete. Never use services for operations that take more than ~1 second—use actions instead (covered below).
Service Type Anatomy
Services consist of a request message and a response message. Example: AddTwoInts.srv
# Request
int64 a
int64 b
---
# Response
int64 sum
The --- separator divides request from response. For humanoid robotics, common service types include:
SetBool: Enable/disable a controllerTrigger: Initiate calibration or homingGetPose: Query end-effector position
Service Server Example: Inverse Kinematics Calculator
This server computes joint angles needed to position a humanoid's hand at a target location—a fundamental operation for manipulation tasks.
#!/usr/bin/env python3
"""
Inverse kinematics service for humanoid arm.
Computes joint angles to reach target end-effector pose.
"""
import rclpy
from rclpy.node import Node
from geometry_msgs.srv import GetPlan
from geometry_msgs.msg import Pose, Point, Quaternion
from sensor_msgs.msg import JointState
import math
class IKService(Node):
"""
Provides inverse kinematics solving as a service.
Simplified 2-DOF arm for demonstration.
"""
def __init__(self):
super().__init__('ik_service')
# Create service server on /compute_ik topic
# Service type: custom message defined in package
self.srv = self.create_service(
GetPlan, # Reusing existing type for demonstration
'compute_ik',
self.compute_ik_callback
)
# Arm parameters (meters)
self.upper_arm_length = 0.3 # Shoulder to elbow
self.forearm_length = 0.25 # Elbow to wrist
self.get_logger().info('IK service ready')
def compute_ik_callback(self, request, response):
"""
Solve inverse kinematics for 2-DOF planar arm.
Args:
request: Contains target pose (position and orientation)
response: Populated with joint angles
Returns:
response: Modified response object (ROS 2 convention)
"""
# Extract target position from request
target_x = request.goal.pose.position.x
target_y = request.goal.pose.position.y
self.get_logger().info(f'IK request: target=({target_x:.3f}, {target_y:.3f})')
# Calculate distance to target
distance = math.sqrt(target_x**2 + target_y**2)
# Check if target is reachable
max_reach = self.upper_arm_length + self.forearm_length
min_reach = abs(self.upper_arm_length - self.forearm_length)
if distance > max_reach or distance < min_reach:
self.get_logger().error(
f'Target unreachable: distance={distance:.3f}m, '
f'valid range=[{min_reach:.3f}, {max_reach:.3f}]'
)
# Return empty response to indicate failure
return response
# Compute elbow angle using law of cosines
# c² = a² + b² - 2ab*cos(C)
cos_elbow = (
(target_x**2 + target_y**2 -
self.upper_arm_length**2 - self.forearm_length**2) /
(2 * self.upper_arm_length * self.forearm_length)
)
# Clamp to [-1, 1] to avoid numerical errors
cos_elbow = max(-1.0, min(1.0, cos_elbow))
elbow_angle = math.acos(cos_elbow)
# Compute shoulder angle
alpha = math.atan2(target_y, target_x)
beta = math.atan2(
self.forearm_length * math.sin(elbow_angle),
self.upper_arm_length + self.forearm_length * math.cos(elbow_angle)
)
shoulder_angle = alpha - beta
# Populate response (in production, return JointState message)
self.get_logger().info(
f'IK solution: shoulder={math.degrees(shoulder_angle):.1f}°, '
f'elbow={math.degrees(elbow_angle):.1f}°'
)
# For demonstration, encode angles in response
# In real implementation, define custom service type with JointState response
response.plan.poses = [] # Placeholder
return response
def main(args=None):
rclpy.init(args=args)
node = IKService()
try:
rclpy.spin(node)
except KeyboardInterrupt:
node.get_logger().info('Shutting down IK service')
finally:
node.destroy_node()
rclpy.shutdown()
if __name__ == '__main__':
main()
Service Client Example
#!/usr/bin/env python3
"""
Client that requests inverse kinematics solutions.
"""
import rclpy
from rclpy.node import Node
from geometry_msgs.srv import GetPlan
from geometry_msgs.msg import PoseStamped, Point
class IKClient(Node):
def __init__(self):
super().__init__('ik_client')
# Create service client
self.client = self.create_client(GetPlan, 'compute_ik')
# Wait for service to become available (with 5 second timeout)
self.get_logger().info('Waiting for IK service...')
if not self.client.wait_for_service(timeout_sec=5.0):
self.get_logger().error('IK service not available')
return
self.get_logger().info('IK service connected')
def send_request(self, x, y):
"""
Send IK request for target position.
Args:
x (float): Target x coordinate (meters)
y (float): Target y coordinate (meters)
"""
# Create request message
request = GetPlan.Request()
request.goal = PoseStamped()
request.goal.pose.position = Point(x=x, y=y, z=0.0)
# Send request asynchronously (non-blocking)
future = self.client.call_async(request)
# Register callback for when response arrives
future.add_done_callback(self.handle_response)
def handle_response(self, future):
"""
Called when service response is received.
Args:
future: Future object containing response
"""
try:
response = future.result()
self.get_logger().info('IK solution received')
# Process response.plan data here
except Exception as e:
self.get_logger().error(f'Service call failed: {e}')
def main(args=None):
rclpy.init(args=args)
client = IKClient()
# Request IK for position (0.4, 0.3)
client.send_request(0.4, 0.3)
# Spin to process callbacks
rclpy.spin(client)
if __name__ == '__main__':
main()
Action Servers: Long-Running Tasks
Actions extend services for operations that take significant time (seconds to minutes) and require progress feedback. Examples include:
- Walking to a destination (report distance remaining)
- Grasping an object (report contact forces during approach)
- Standup sequence (report completion of each phase)
Action Structure
Actions have three components:
- Goal: Request message (e.g., target position for walking)
- Result: Final outcome (e.g., success/failure, final pose)
- Feedback: Periodic progress updates (e.g., current distance to goal)
Actions also support cancellation—critical for safety when a humanoid must abort a motion.
Action Server Example: Walk to Position
#!/usr/bin/env python3
"""
Action server for humanoid walking.
Executes walk commands with progress feedback.
"""
import rclpy
from rclpy.action import ActionServer
from rclpy.node import Node
from action_msgs.msg import GoalStatus
# In production, define custom action: WalkToPosition.action
# For demo, using example action type
from example_interfaces.action import Fibonacci
import time
class WalkActionServer(Node):
"""
Executes walking motions as long-running actions.
"""
def __init__(self):
super().__init__('walk_action_server')
# Create action server
self._action_server = ActionServer(
self,
Fibonacci, # Replace with custom WalkToPosition action
'walk_to_position',
self.execute_callback
)
# Walking parameters
self.walking_speed = 0.5 # m/s
self.get_logger().info('Walk action server started')
def execute_callback(self, goal_handle):
"""
Execute walking action.
Args:
goal_handle: Handle for managing action execution
Returns:
Result message
"""
self.get_logger().info('Executing walk action')
# Extract goal (in real action, this would be target pose)
target_distance = 2.0 # meters
steps_required = int(target_distance / self.walking_speed)
# Create feedback message
feedback_msg = Fibonacci.Feedback()
# Simulate walking with periodic feedback
for step in range(steps_required):
# Check if cancellation requested
if goal_handle.is_cancel_requested:
goal_handle.canceled()
self.get_logger().info('Walk action canceled')
return Fibonacci.Result()
# Compute progress
distance_covered = step * self.walking_speed
distance_remaining = target_distance - distance_covered
# Publish feedback (in real implementation, include current pose)
feedback_msg.sequence = [int(distance_covered * 100), int(distance_remaining * 100)]
goal_handle.publish_feedback(feedback_msg)
self.get_logger().info(
f'Walking: {distance_covered:.2f}m covered, '
f'{distance_remaining:.2f}m remaining'
)
# Simulate one second of walking
time.sleep(1.0)
# Mark action as succeeded
goal_handle.succeed()
# Return result
result = Fibonacci.Result()
result.sequence = [int(target_distance * 100)]
self.get_logger().info(f'Walk completed: {target_distance}m')
return result
def main(args=None):
rclpy.init(args=args)
node = WalkActionServer()
try:
rclpy.spin(node)
except KeyboardInterrupt:
node.get_logger().info('Shutting down walk action server')
finally:
node.destroy_node()
rclpy.shutdown()
if __name__ == '__main__':
main()
Parameters and Dynamic Reconfigure
Parameters allow runtime configuration without restarting nodes—essential for tuning controller gains during testing.
#!/usr/bin/env python3
"""
Demonstrates ROS 2 parameter usage for controller tuning.
"""
import rclpy
from rclpy.node import Node
from rcl_interfaces.msg import SetParametersResult
class BalanceController(Node):
def __init__(self):
super().__init__('balance_controller')
# Declare parameters with default values
self.declare_parameter('kp_pitch', 50.0) # Proportional gain for pitch
self.declare_parameter('kd_pitch', 10.0) # Derivative gain
self.declare_parameter('kp_roll', 50.0)
self.declare_parameter('kd_roll', 10.0)
self.declare_parameter('max_torque', 100.0) # Nm
# Register callback for parameter changes
self.add_on_set_parameters_callback(self.parameter_callback)
# Read initial parameter values
self.update_gains()
self.get_logger().info(
f'Balance controller initialized: '
f'kp_pitch={self.kp_pitch}, kd_pitch={self.kd_pitch}'
)
def update_gains(self):
"""Read current parameter values."""
self.kp_pitch = self.get_parameter('kp_pitch').value
self.kd_pitch = self.get_parameter('kd_pitch').value
self.kp_roll = self.get_parameter('kp_roll').value
self.kd_roll = self.get_parameter('kd_roll').value
self.max_torque = self.get_parameter('max_torque').value
def parameter_callback(self, params):
"""
Called when parameters are changed via CLI or service.
Args:
params: List of parameters being modified
Returns:
SetParametersResult: Success/failure indicator
"""
for param in params:
self.get_logger().info(f'Parameter changed: {param.name} = {param.value}')
# Update internal gains
self.update_gains()
# Validate parameters (example: ensure gains are positive)
if self.kp_pitch < 0 or self.kd_pitch < 0:
self.get_logger().error('Gains must be positive')
return SetParametersResult(successful=False)
return SetParametersResult(successful=True)
def main(args=None):
rclpy.init(args=args)
node = BalanceController()
rclpy.spin(node)
if __name__ == '__main__':
main()
Using Parameters from CLI
# Get current parameter values
ros2 param get /balance_controller kp_pitch
# Set new value (triggers callback)
ros2 param set /balance_controller kp_pitch 75.0
# List all parameters for a node
ros2 param list /balance_controller
# Save parameters to YAML file
ros2 param dump /balance_controller > controller_params.yaml
# Load parameters from file on startup
ros2 run humanoid_control balance_controller --ros-args --params-file controller_params.yaml
Next Steps
You now understand services for request-response operations, actions for long-running tasks with feedback, and parameters for runtime configuration. The next chapter, Week 5: URDF, introduces robot modeling—defining the kinematic structure of a humanoid robot for simulation and control.
Practice Exercise
Create an action client that:
- Sends a walk goal to the action server
- Displays progress feedback in the terminal
- Cancels the action if user presses 'q'
Hint: Use rclpy.action.ActionClient and register callbacks for feedback, result, and goal_response.
