Week 10: Navigation with Nav2

Introduction to Nav2

Nav2 (Navigation2) is the ROS 2 navigation stack that enables autonomous robot movement. Originally designed for wheeled robots, Nav2 can be adapted for bipedal humanoid navigation with appropriate configuration.

Nav2 Architecture

Nav2 consists of modular components (servers) that work together:

1. Map Server: Provides occupancy grid map (free space vs. obstacles)
2. AMCL: Adaptive Monte Carlo Localization for pose estimation
3. Planner Server: Computes global path from start to goal
4. Controller Server: Generates velocity commands to follow the path
5. Recovery Server: Executes behaviors when navigation fails (spinning, backing up)
6. Behavior Tree Navigator: Orchestrates the above components

# Conceptual Nav2 pipeline
def navigate_to_goal(goal_pose):
    # 1. Localize robot on map
    current_pose = amcl.get_pose()

    # 2. Plan global path
    global_path = planner.make_plan(current_pose, goal_pose)

    # 3. Follow path with local planning
    while not at_goal:
        local_plan = controller.compute_velocity_commands(global_path, current_pose)
        robot.execute_velocity(local_plan)

        # Handle obstacles
        if path_blocked:
            recovery.execute_recovery()

Costmaps for Humanoid Navigation

Costmaps represent the environment as a grid where each cell has a cost (0 = free, 255 = obstacle). Humanoids require special considerations:

Key Differences from Wheeled Robots

1. Footprint Shape: Rectangular footprint representing bipedal stance width
2. Inflation Radius: Smaller due to humanoid's ability to navigate tight spaces
3. Height Clearance: Must account for humanoid's tall vertical profile
4. Dynamic Stability: Cannot stop instantly - requires forward motion planning

Humanoid Costmap Configuration

# costmap_params.yaml - Configured for bipedal humanoid
global_costmap:
  global_frame: map
  robot_base_frame: base_link
  update_frequency: 5.0      # Hz - update global costmap
  publish_frequency: 2.0

  # Costmap size
  width: 20                  # 20 meter x 20 meter map
  height: 20
  resolution: 0.05           # 5cm grid cells

  # Humanoid footprint (30cm wide stance, 50cm long including step)
  footprint: [
    [0.25, 0.15],   # Front-right
    [0.25, -0.15],  # Front-left
    [-0.25, -0.15], # Back-left
    [-0.25, 0.15]   # Back-right
  ]

  plugins: ["static_layer", "obstacle_layer", "inflation_layer"]

  static_layer:
    plugin: "nav2_costmap_2d::StaticLayer"
    map_subscribe_transient_local: True

  obstacle_layer:
    plugin: "nav2_costmap_2d::ObstacleLayer"
    observation_sources: scan lidar

    # Use 2D lidar for ground-level obstacles
    scan:
      topic: /scan
      max_obstacle_height: 2.0  # Detect obstacles up to 2m (humanoid height)
      clearing_range: 5.0
      raytrace_range: 6.0

    # Use 3D lidar/camera for full environment perception
    lidar:
      topic: /points
      max_obstacle_height: 2.5
      min_obstacle_height: 0.1  # Ignore ground

  inflation_layer:
    plugin: "nav2_costmap_2d::InflationLayer"
    cost_scaling_factor: 3.0
    inflation_radius: 0.35  # Smaller than wheeled (humanoid agility)

# Local costmap for dynamic obstacle avoidance
local_costmap:
  global_frame: odom
  robot_base_frame: base_link
  update_frequency: 10.0     # Higher update rate for reactive navigation
  publish_frequency: 5.0

  width: 5                   # 5m x 5m local window
  height: 5
  resolution: 0.05

  footprint: [
    [0.25, 0.15],
    [0.25, -0.15],
    [-0.25, -0.15],
    [-0.25, 0.15]
  ]

  plugins: ["voxel_layer", "inflation_layer"]

  voxel_layer:
    plugin: "nav2_costmap_2d::VoxelLayer"
    enabled: True
    publish_voxel_map: True
    origin_z: 0.0
    z_resolution: 0.2        # 20cm vertical resolution
    z_voxels: 10             # 2m height (10 * 0.2m)
    max_obstacle_height: 2.0
    mark_threshold: 2        # Cells with 2+ hits marked as obstacle

Path Planning Algorithms

Nav2 supports multiple global planners. Humanoids benefit from Dijkstra or A* for stable, predictable paths.

Dijkstra vs. A*

# Dijkstra: explores uniformly in all directions
def dijkstra(start, goal, costmap):
    visited = set()
    priority_queue = [(0, start)]  # (cost, node)

    while priority_queue:
        cost, current = heappop(priority_queue)
        if current == goal:
            return reconstruct_path(current)

        for neighbor in get_neighbors(current, costmap):
            new_cost = cost + costmap[neighbor]
            if neighbor not in visited:
                visited.add(neighbor)
                heappush(priority_queue, (new_cost, neighbor))

# A*: uses heuristic to guide search toward goal
def a_star(start, goal, costmap):
    visited = set()
    priority_queue = [(heuristic(start, goal), 0, start)]  # (f, g, node)

    while priority_queue:
        f, g, current = heappop(priority_queue)
        if current == goal:
            return reconstruct_path(current)

        for neighbor in get_neighbors(current, costmap):
            new_g = g + costmap[neighbor]
            new_f = new_g + heuristic(neighbor, goal)  # f = g + h
            if neighbor not in visited:
                visited.add(neighbor)
                heappush(priority_queue, (new_f, new_g, neighbor))

def heuristic(node, goal):
    # Euclidean distance as heuristic
    return sqrt((node.x - goal.x)**2 + (node.y - goal.y)**2)

Planner Configuration

# planner_server_params.yaml
planner_server:
  ros__parameters:
    expected_planner_frequency: 2.0  # Plan every 0.5s

    plugins: ["GridBased"]

    GridBased:
      plugin: "nav2_navfn_planner/NavfnPlanner"  # A* implementation
      tolerance: 0.1              # 10cm goal tolerance
      use_astar: True             # Use A* (False = Dijkstra)
      allow_unknown: False        # Don't plan through unexplored areas
      use_final_approach_orientation: True  # Orient toward goal

Controller for Bipedal Motion

The DWB (Dynamic Window Approach) controller generates velocity commands that respect kinodynamic constraints.

Bipedal-Specific Constraints

# controller_params.yaml
controller_server:
  ros__parameters:
    controller_frequency: 20.0  # 20 Hz control loop

    plugins: ["FollowPath"]

    FollowPath:
      plugin: "dwb_core::DWBLocalPlanner"

      # Bipedal velocity limits (slower than wheeled robots)
      min_vel_x: 0.1            # Must maintain forward motion for stability
      max_vel_x: 0.5            # 0.5 m/s max walking speed
      min_vel_y: -0.2           # Limited lateral movement
      max_vel_y: 0.2
      max_vel_theta: 0.3        # 0.3 rad/s turning speed

      # Acceleration limits (gradual for balance)
      acc_lim_x: 0.3            # 0.3 m/s² (gentle acceleration)
      acc_lim_y: 0.2
      acc_lim_theta: 0.5
      decel_lim_x: -0.3         # Gentle deceleration

      # Trajectory scoring
      critics: [
        "RotateToGoal",
        "Oscillation",
        "BaseObstacle",
        "GoalAlign",
        "PathAlign",
        "PathDist",
        "GoalDist"
      ]

      # Critic weights (tune for humanoid behavior)
      PathAlign.scale: 32.0      # Strongly prefer following global path
      GoalAlign.scale: 24.0      # Orient toward goal
      PathDist.scale: 32.0
      GoalDist.scale: 24.0
      BaseObstacle.scale: 0.02   # Obstacle avoidance

      # Simulation parameters
      sim_time: 2.0              # Simulate trajectories 2 seconds ahead
      vx_samples: 10             # Sample 10 velocities per dimension
      vy_samples: 5
      vtheta_samples: 10

      # Trajectory constraints
      trajectory_generator_name: "dwb_plugins::StandardTrajectoryGenerator"

Recovery Behaviors

When navigation fails, recovery behaviors attempt to get the robot unstuck.

Humanoid-Safe Recovery Sequence

# behavior_tree_params.yaml
bt_navigator:
  ros__parameters:
    plugin_lib_names:
      - nav2_compute_path_to_pose_action_bt_node
      - nav2_follow_path_action_bt_node
      - nav2_back_up_action_bt_node
      - nav2_spin_action_bt_node
      - nav2_wait_action_bt_node

    # Recovery behavior parameters
    global_frame: map
    robot_base_frame: base_link
    transform_tolerance: 0.1

    # Recovery sequence for humanoids (gentle, stable motions)
    default_nav_through_poses_bt_xml: ""
    default_nav_to_pose_bt_xml: ""

    # Spin recovery - rotate in place to clear sensors
    spin:
      simulate_ahead_time: 2.0
      max_rotational_vel: 0.2     # Slow rotation for stability
      min_rotational_vel: 0.1
      rotational_acc_lim: 0.3

    # Backup recovery - step backward
    backup:
      simulate_ahead_time: 2.0
      backup_dist: 0.3            # Small 30cm backup
      backup_speed: 0.1           # Slow, controlled

Launching Nav2 for Humanoid

# humanoid_nav2_launch.py
from launch import LaunchDescription
from launch_ros.actions import Node
from ament_index_python.packages import get_package_share_directory
import os

def generate_launch_description():
    pkg_dir = get_package_share_directory('humanoid_navigation')

    return LaunchDescription([
        # Map server - load pre-built map
        Node(
            package='nav2_map_server',
            executable='map_server',
            name='map_server',
            parameters=[{
                'yaml_filename': os.path.join(pkg_dir, 'maps', 'office.yaml'),
                'use_sim_time': False
            }]
        ),

        # AMCL localization
        Node(
            package='nav2_amcl',
            executable='amcl',
            name='amcl',
            parameters=[os.path.join(pkg_dir, 'config', 'amcl_params.yaml')]
        ),

        # Planner server
        Node(
            package='nav2_planner',
            executable='planner_server',
            name='planner_server',
            parameters=[os.path.join(pkg_dir, 'config', 'planner_params.yaml')]
        ),

        # Controller server
        Node(
            package='nav2_controller',
            executable='controller_server',
            name='controller_server',
            parameters=[os.path.join(pkg_dir, 'config', 'controller_params.yaml')]
        ),

        # Recovery server
        Node(
            package='nav2_recoveries',
            executable='recoveries_server',
            name='recoveries_server',
            parameters=[os.path.join(pkg_dir, 'config', 'recovery_params.yaml')]
        ),

        # Behavior tree navigator
        Node(
            package='nav2_bt_navigator',
            executable='bt_navigator',
            name='bt_navigator',
            parameters=[os.path.join(pkg_dir, 'config', 'bt_navigator_params.yaml')]
        ),

        # Lifecycle manager
        Node(
            package='nav2_lifecycle_manager',
            executable='lifecycle_manager',
            name='lifecycle_manager_navigation',
            parameters=[{
                'autostart': True,
                'node_names': [
                    'map_server',
                    'amcl',
                    'planner_server',
                    'controller_server',
                    'recoveries_server',
                    'bt_navigator'
                ]
            }]
        )
    ])

Exercises

1. Costmap Tuning: Adjust footprint and inflation radius for your simulated humanoid. Observe effects on path planning.

2. Algorithm Comparison: Run navigation with Dijkstra and A* planners. Measure planning time and path length differences.

3. Recovery Testing: Place the robot in a tight corner and trigger recovery behaviors. Observe which sequence successfully escapes.

4. Dynamic Obstacles: Add moving obstacles to the environment and observe local planner's avoidance behavior.

---
