Week 11: Voice-to-Action Pipeline

Speech Recognition with OpenAI Whisper

OpenAI Whisper is a state-of-the-art automatic speech recognition (ASR) system trained on 680,000 hours of multilingual data. Unlike traditional ASR models requiring custom wake-word detection and language-specific training, Whisper provides zero-shot transcription across 99 languages with robust performance in noisy environments—critical for humanoid robots operating in homes, factories, and public spaces.

Why Whisper for Robotics?

Noise Robustness: Whisper's training included diverse acoustic conditions (background music, overlapping speech, machinery noise). A humanoid working in a kitchen can transcribe commands over running dishwashers and conversations.

Multilingual Support: Global deployments require multi-language interfaces. Whisper handles code-switching (mixing languages mid-sentence) common in multilingual households.

No Fine-Tuning Required: Unlike domain-specific ASR models, Whisper generalizes to robotics vocabulary ("grasp the Phillips screwdriver") without custom training.

Installation and Setup

# Install Whisper and dependencies
# Requires ffmpeg for audio processing: sudo apt install ffmpeg
import subprocess
subprocess.run(["pip", "install", "openai-whisper", "sounddevice", "numpy"])

import whisper
import sounddevice as sd
import numpy as np
from scipy.io.wavfile import write

# Load Whisper model (options: tiny, base, small, medium, large)
# Trade-off: larger models = better accuracy but slower inference
# For real-time robotics: 'base' (74M params) achieves <0.5s latency on GPU
model = whisper.load_model("base")  # Downloads ~140MB on first run

def record_audio(duration=5, sample_rate=16000):
    """
    Record audio from microphone for specified duration.

    Args:
        duration: Recording length in seconds
        sample_rate: Hz (16kHz is Whisper's native rate, avoids resampling)

    Returns:
        numpy array: Audio samples in range [-1, 1]
    """
    print(f"Recording for {duration} seconds...")
    # Record from default microphone (set device index for specific mic)
    audio = sd.rec(
        int(duration * sample_rate),
        samplerate=sample_rate,
        channels=1,  # Mono audio
        dtype='float32'
    )
    sd.wait()  # Block until recording completes
    print("Recording complete.")
    return audio.flatten()

def transcribe_audio(audio_array):
    """
    Transcribe audio to text using Whisper.

    Args:
        audio_array: NumPy array of audio samples

    Returns:
        dict: Transcription result with 'text', 'language', 'segments'
    """
    # Whisper expects float32 audio normalized to [-1, 1]
    result = model.transcribe(
        audio_array,
        language='en',  # Set to None for auto-detection (adds latency)
        task='transcribe',  # Alternative: 'translate' for non-English to English
        fp16=True  # Enable half-precision for 2x speed on GPU
    )
    return result

# Example usage: Record and transcribe
audio = record_audio(duration=5)
result = transcribe_audio(audio)
print(f"Transcription: {result['text']}")
# Output example: "Robot, pick up the red mug and place it on the table."

Command Parsing and Intent Classification

Raw transcriptions require parsing into structured robot commands. We extract intent (what action), entities (target objects), and parameters (locations, quantities).

Rule-Based Parsing

For constrained vocabularies (warehouse robots with fixed commands), rule-based parsing suffices:

import re
from typing import Dict, List, Optional

class CommandParser:
    """
    Parse natural language into structured robot commands.
    Handles imperative sentences with action verbs and object references.
    """

    # Define action vocabulary with synonyms
    ACTION_VERBS = {
        'pick': ['pick', 'grab', 'grasp', 'take', 'lift'],
        'place': ['place', 'put', 'set', 'drop', 'position'],
        'navigate': ['go', 'move', 'walk', 'navigate', 'travel'],
        'open': ['open'],
        'close': ['close', 'shut']
    }

    # Spatial prepositions for location extraction
    LOCATIONS = ['on', 'in', 'under', 'next to', 'above', 'below', 'near']

    def __init__(self):
        # Compile regex patterns for efficiency
        self.action_pattern = self._build_action_pattern()

    def _build_action_pattern(self) -> re.Pattern:
        """Create regex matching any action verb."""
        all_verbs = [v for synonyms in self.ACTION_VERBS.values() for v in synonyms]
        pattern = r'\b(' + '|'.join(all_verbs) + r')\b'
        return re.compile(pattern, re.IGNORECASE)

    def parse(self, text: str) -> Dict:
        """
        Extract intent and entities from command.

        Args:
            text: Natural language command

        Returns:
            dict: {
                'intent': str,
                'object': str,
                'location': str,
                'confidence': float
            }
        """
        text = text.lower().strip()

        # Extract action intent
        action_match = self.action_pattern.search(text)
        if not action_match:
            return {'intent': 'unknown', 'confidence': 0.0}

        verb = action_match.group(1)
        intent = self._map_verb_to_intent(verb)

        # Extract target object (noun after action verb)
        object_match = re.search(
            r'\b(?:the\s+)?(\w+(?:\s+\w+)?)\b',  # Captures "red mug" or "mug"
            text[action_match.end():]
        )
        target_object = object_match.group(1) if object_match else None

        # Extract location (prepositional phrase)
        location = self._extract_location(text)

        return {
            'intent': intent,
            'object': target_object,
            'location': location,
            'confidence': 0.95 if target_object else 0.6
        }

    def _map_verb_to_intent(self, verb: str) -> str:
        """Map detected verb to canonical intent."""
        for intent, synonyms in self.ACTION_VERBS.items():
            if verb in synonyms:
                return intent
        return 'unknown'

    def _extract_location(self, text: str) -> Optional[str]:
        """Extract location phrase (e.g., 'on the table')."""
        for prep in self.LOCATIONS:
            pattern = f'{prep}\\s+(?:the\\s+)?(\\w+(?:\\s+\\w+)?)'
            match = re.search(pattern, text)
            if match:
                return f"{prep} {match.group(1)}"
        return None

# Example usage
parser = CommandParser()
commands = [
    "Pick up the red mug",
    "Place it on the table",
    "Go to the kitchen",
    "Open the drawer"
]

for cmd in commands:
    result = parser.parse(cmd)
    print(f"Input: {cmd}")
    print(f"Parsed: {result}\n")

# Output:
# Input: Pick up the red mug
# Parsed: {'intent': 'pick', 'object': 'red mug', 'location': None, 'confidence': 0.95}

LLM-Based Intent Classification

For open-ended commands, use GPT-4 for semantic understanding:

import openai
import os
import json

# Set API key from environment variable (never hardcode secrets)
openai.api_key = os.getenv("OPENAI_API_KEY")

def classify_intent_with_llm(command: str) -> Dict:
    """
    Use GPT-4 to extract structured intent from natural language.
    Handles complex commands like 'After closing the door, bring me water.'

    Args:
        command: Natural language instruction

    Returns:
        dict: Structured command with intent, parameters, and sequence
    """
    # System prompt defines robot's capabilities and output format
    system_prompt = """You are a command parser for a humanoid robot.
    Extract intent, objects, locations, and action sequences from user commands.

    Available actions: pick, place, navigate, open, close, wait.

    Return JSON with format:
    {
        "actions": [
            {"intent": "action", "object": "item", "location": "place", "parameters": {}}
        ],
        "confidence": 0.0-1.0
    }
    """

    # Few-shot examples improve parsing accuracy
    user_prompt = f"""Command: {command}

    Examples:
    Input: "Grab the blue cup and put it in the sink"
    Output: {{"actions": [{{"intent": "pick", "object": "blue cup"}}, {{"intent": "place", "location": "sink"}}], "confidence": 0.95}}

    Input: "Go to the bedroom"
    Output: {{"actions": [{{"intent": "navigate", "location": "bedroom"}}], "confidence": 0.98}}

    Now parse the command above.
    """

    response = openai.ChatCompletion.create(
        model="gpt-4",  # Use gpt-3.5-turbo for faster/cheaper inference
        messages=[
            {"role": "system", "content": system_prompt},
            {"role": "user", "content": user_prompt}
        ],
        temperature=0.0,  # Deterministic output for command parsing
        max_tokens=200
    )

    # Extract JSON from response
    result_text = response.choices[0].message.content
    try:
        return json.loads(result_text)
    except json.JSONDecodeError:
        return {"actions": [], "confidence": 0.0, "error": "Parse failed"}

# Example: Complex multi-step command
command = "First go to the kitchen, then pick up the green bottle and bring it here."
intent = classify_intent_with_llm(command)
print(json.dumps(intent, indent=2))

# Output:
# {
#   "actions": [
#     {"intent": "navigate", "location": "kitchen"},
#     {"intent": "pick", "object": "green bottle"},
#     {"intent": "navigate", "location": "user"}
#   ],
#   "confidence": 0.92
# }

Voice Interface Design

Effective human-robot voice interaction requires:

Wake Word Detection: Use lightweight models (Porcupine, Snowboy) to activate listening only on "Hey Robot", reducing false activations.

Confirmation Loops: Repeat parsed commands back to user: "I will pick up the red mug. Proceed?" Prevents misunderstandings before execution.

Feedback: Provide audio acknowledgments during long operations: "Navigating to kitchen... Arrived. Searching for green bottle..."

Practice Exercise

Implement a complete voice command pipeline:

1. Record 5-second audio clip
2. Transcribe with Whisper
3. Parse intent with rule-based parser
4. Generate ROS 2 action goal for robot execution

Extend the parser to handle negations ("Don't pick up the blue cup") and conditionals ("If the door is open, go through it").

Next Steps

You've built the perception layer (speech → text → intent). In Week 11: LLM Planning, you'll use GPT-4 to generate multi-step task plans, implementing the ReAct pattern for adaptive reasoning during execution.
