Week 12: Multimodal Vision-Language Fusion
Vision and Language Integrationβ
Multimodal models jointly process visual and textual data to ground language in physical perception. For robotics, this enables referring to objects by natural descriptions ("the mug with the red handle") rather than pre-defined IDs or bounding box coordinates. Vision-language fusion is essential for embodied AI agents operating in open-world environments with novel, unnamed objects.
Why Multimodal Models?β
Zero-Shot Object Recognition: Traditional object detectors require training on labeled datasets. Multimodal models leverage language descriptions to recognize new categories without retrainingβa humanoid encountering "quinoa" for the first time can identify it via text-image similarity.
Spatial Reasoning: Language models encode spatial relationships ("left of", "behind") but lack visual grounding. Vision-language models learn to map these linguistic concepts to pixel coordinates.
Disambiguation: In scenes with multiple similar objects ("the red mug on the left"), visual grounding resolves which instance matches the description.
CLIP for Visual Groundingβ
CLIP (Contrastive Language-Image Pre-training) learns a shared embedding space for images and text by training on 400 million image-caption pairs scraped from the internet. Given an image and multiple text descriptions, CLIP computes similarity scores to determine the best match.
Installation and Basic Usageβ
# Install CLIP from OpenAI's official repository
import subprocess
subprocess.run(["pip", "install", "git+https://github.com/openai/CLIP.git", "pillow", "torch"])
import torch
import clip
from PIL import Image
import numpy as np
# Load pre-trained CLIP model
# Options: RN50, RN101, ViT-B/32, ViT-L/14 (larger = more accurate but slower)
device = "cuda" if torch.cuda.is_available() else "cpu"
model, preprocess = clip.load("ViT-B/32", device=device)
def ground_object_in_image(image_path: str, text_queries: list) -> dict:
"""
Find which text description best matches the image.
Args:
image_path: Path to image file
text_queries: List of text descriptions to compare
Returns:
dict: {
'best_match': str,
'scores': dict mapping query to similarity score
}
"""
# Load and preprocess image
image = Image.open(image_path)
image_input = preprocess(image).unsqueeze(0).to(device)
# Tokenize text queries
text_inputs = clip.tokenize(text_queries).to(device)
# Compute embeddings
with torch.no_grad():
image_features = model.encode_image(image_input) # Shape: [1, 512]
text_features = model.encode_text(text_inputs) # Shape: [N, 512]
# Normalize features to unit vectors
image_features /= image_features.norm(dim=-1, keepdim=True)
text_features /= text_features.norm(dim=-1, keepdim=True)
# Compute cosine similarity (dot product of unit vectors)
similarity = (image_features @ text_features.T).squeeze(0) # Shape: [N]
# Convert to probabilities using softmax
probabilities = similarity.softmax(dim=0).cpu().numpy()
# Create results dictionary
scores = {query: float(prob) for query, prob in zip(text_queries, probabilities)}
best_match = text_queries[probabilities.argmax()]
return {
'best_match': best_match,
'scores': scores
}
# Example: Object classification in kitchen scene
queries = [
"a red coffee mug",
"a white plate",
"a stainless steel fork",
"a glass of water"
]
result = ground_object_in_image("kitchen_counter.jpg", queries)
print(f"Best match: {result['best_match']}")
print("\nAll scores:")
for query, score in result['scores'].items():
print(f" {query}: {score:.3f}")
# Output:
# Best match: a red coffee mug
# All scores:
# a red coffee mug: 0.782
# a white plate: 0.124
# a stainless steel fork: 0.061
# a glass of water: 0.033
Referring Expressions for Object Selectionβ
Referring expressions uniquely identify objects using attributes (color, shape), spatial relations (left, behind), and functional descriptions (for drinking). Unlike simple object detection, this requires compositional reasoning.
Spatial Grounding with CLIPβ
import cv2
from typing import List, Tuple
def detect_objects_with_clip(
image_path: str,
object_descriptions: List[str],
grid_size: int = 8
) -> List[Tuple[str, int, int, float]]:
"""
Localize objects in image using sliding window CLIP scoring.
Args:
image_path: Input image
object_descriptions: List of text descriptions to search for
grid_size: Divide image into grid_size x grid_size regions
Returns:
List of (description, x, y, score) for detected objects
"""
# Load image
image = Image.open(image_path)
img_width, img_height = image.size
# Calculate region dimensions
region_width = img_width // grid_size
region_height = img_height // grid_size
detections = []
for desc in object_descriptions:
best_score = 0
best_position = (0, 0)
# Slide over grid regions
for i in range(grid_size):
for j in range(grid_size):
# Extract region
left = j * region_width
top = i * region_height
right = left + region_width
bottom = top + region_height
region = image.crop((left, top, right, bottom))
region_input = preprocess(region).unsqueeze(0).to(device)
# Compute CLIP score for this region
text_input = clip.tokenize([desc]).to(device)
with torch.no_grad():
image_features = model.encode_image(region_input)
text_features = model.encode_text(text_input)
image_features /= image_features.norm(dim=-1, keepdim=True)
text_features /= text_features.norm(dim=-1, keepdim=True)
score = (image_features @ text_features.T).item()
# Track highest scoring region for this object
if score > best_score:
best_score = score
best_position = (left + region_width // 2, top + region_height // 2)
detections.append((desc, best_position[0], best_position[1], best_score))
return detections
# Example: Locate multiple objects
objects = ["red mug", "laptop computer", "potted plant"]
detections = detect_objects_with_clip("desk_scene.jpg", objects, grid_size=6)
for obj, x, y, score in detections:
print(f"{obj}: position ({x}, {y}), confidence {score:.3f}")
# Visualize results
image = cv2.imread("desk_scene.jpg")
for obj, x, y, score in detections:
cv2.circle(image, (x, y), 10, (0, 255, 0), -1)
cv2.putText(image, obj, (x + 15, y), cv2.FONT_HERSHEY_SIMPLEX, 0.5, (255, 255, 255), 2)
cv2.imwrite("detected_objects.jpg", image)
Visual Question Answering (VQA)β
Visual Question Answering combines image understanding with language comprehension to answer open-ended questions about visual scenes. For humanoid robots, VQA enables situational awareness: "Is the door open?", "How many people are in the room?", "What color is the object on the table?"
VQA with GPT-4V (Vision)β
import base64
import requests
def answer_visual_question(image_path: str, question: str) -> str:
"""
Use GPT-4V to answer questions about an image.
Args:
image_path: Path to image file
question: Natural language question
Returns:
str: Answer from GPT-4V
"""
# Encode image to base64 for API transmission
with open(image_path, "rb") as image_file:
image_data = base64.b64encode(image_file.read()).decode('utf-8')
headers = {
"Content-Type": "application/json",
"Authorization": f"Bearer {os.getenv('OPENAI_API_KEY')}"
}
# Construct multimodal prompt
payload = {
"model": "gpt-4-vision-preview",
"messages": [
{
"role": "user",
"content": [
{
"type": "text",
"text": question
},
{
"type": "image_url",
"image_url": {
}
}
]
}
],
"max_tokens": 300
}
# Send API request
response = requests.post(
"https://api.openai.com/v1/chat/completions",
headers=headers,
json=payload
)
# Extract answer
result = response.json()
answer = result['choices'][0]['message']['content']
return answer
# Example: Scene understanding queries
questions = [
"How many mugs are on the table?",
"What color is the leftmost mug?",
"Is there a laptop visible in the image?",
"Describe the spatial arrangement of objects on the desk."
]
for q in questions:
answer = answer_visual_question("desk_scene.jpg", q)
print(f"Q: {q}")
print(f"A: {answer}\n")
# Output:
# Q: How many mugs are on the table?
# A: There are three mugs visible on the table.
#
# Q: What color is the leftmost mug?
# A: The leftmost mug is red with a white handle.
Integrating Vision-Language with Robot Controlβ
Combine CLIP grounding with ROS 2 action servers for closed-loop manipulation:
import rclpy
from rclpy.node import Node
from geometry_msgs.msg import Point
class VisionLanguageGrasping(Node):
"""
ROS 2 node that uses CLIP to locate objects and commands robot to grasp.
"""
def __init__(self):
super().__init__('vision_language_grasping')
# Subscribe to camera images
self.subscription = self.create_subscription(
Image,
'/camera/image_raw',
self.image_callback,
10
)
# Publisher for grasp target positions
self.grasp_pub = self.create_publisher(Point, '/grasp_target', 10)
self.current_image = None
def image_callback(self, msg):
"""Store latest camera image."""
# Convert ROS Image message to PIL Image
self.current_image = self.ros_to_pil_image(msg)
def grasp_object_by_description(self, description: str):
"""
Find object matching description and publish grasp target.
Args:
description: Text description (e.g., "the blue screwdriver")
"""
if self.current_image is None:
self.get_logger().warn("No camera image available")
return
# Use CLIP to locate object
detections = detect_objects_with_clip(
self.current_image,
[description],
grid_size=8
)
if detections:
desc, x, y, score = detections[0]
self.get_logger().info(
f"Found '{desc}' at pixel ({x}, {y}) with confidence {score:.2f}"
)
# Convert pixel coordinates to 3D point (requires camera calibration)
grasp_point = self.pixel_to_3d(x, y)
# Publish grasp target for manipulation controller
self.grasp_pub.publish(grasp_point)
def pixel_to_3d(self, x: int, y: int) -> Point:
"""
Convert 2D pixel to 3D point using depth sensor and camera intrinsics.
(Simplified; real implementation requires camera_info and depth_image)
"""
point = Point()
point.x = float(x) * 0.001 # Mock conversion
point.y = float(y) * 0.001
point.z = 0.5 # Assume fixed depth
return point
# Example usage in ROS 2 context
def main():
rclpy.init()
node = VisionLanguageGrasping()
# Command robot to grasp object
node.grasp_object_by_description("the red coffee mug")
rclpy.spin(node)
Practice Exerciseβ
Build a visual search system:
- Capture image from robot's camera
- User provides text query: "Find the green bottle"
- Use CLIP to locate object and compute bounding box
- Navigate robot to face object (pan camera or move base)
- Verify object is within manipulation workspace
Extend with attribute reasoning: Handle queries like "the larger of the two mugs" (requires size comparison) or "the mug closest to the edge" (spatial reasoning).
Next Stepsβ
You've connected language to vision for object grounding. In Week 12: Gesture Recognition, you'll add human pose tracking using MediaPipe, enabling robots to interpret pointing gestures and body language for natural human-robot interaction.
