Week 9: Perception for Manipulation
The Manipulation Perception Challenge
Robotic manipulation requires knowing the 6-DOF pose (3D position + 3D orientation) of objects with millimeter-level accuracy. A humanoid robot grasping a cup must know:
- Position (x, y, z): Where is the cup's center?
- Orientation (roll, pitch, yaw): How is the cup rotated?
Traditional 2D object detection only provides bounding boxes, insufficient for 3D grasping.
Object Detection vs. Pose Estimation
2D Object Detection
- Output: [x, y, width, height, class, confidence]
- Use Case: "Is there a cup in the image?"
- Limitation: No depth or orientation information
6-DOF Pose Estimation
- Output: [x, y, z, qw, qx, qy, qz, class, confidence]
- Use Case: "Where exactly is the cup in 3D space?"
- Enables: Grasp planning, collision avoidance, precise placement
DOPE: Deep Object Pose Estimation
DOPE (Deep Object Pose Estimation) is a CNN that predicts 6-DOF poses from RGB images. Trained on synthetic Isaac Sim data, DOPE achieves real-world accuracy through domain randomization.
DOPE Architecture
# Conceptual DOPE pipeline
def dope_inference(rgb_image):
# 1. Feature extraction (ResNet backbone)
features = resnet50(rgb_image)
# 2. Belief maps for 3D keypoints (e.g., object corners)
belief_maps = conv2d(features, num_keypoints=8)
# 3. PnP algorithm to recover 6-DOF pose from 2D keypoints
keypoints_2d = find_peaks(belief_maps)
pose_6dof = solve_pnp(keypoints_2d, keypoints_3d_model, camera_matrix)
return pose_6dof # [x, y, z, quaternion]
Running Isaac ROS DOPE
# Launch file for DOPE object pose estimation
from launch import LaunchDescription
from launch_ros.actions import Node
from launch.actions import DeclareLaunchArgument
from launch.substitutions import LaunchConfiguration
def generate_launch_description():
# Path to trained DOPE model for specific object
model_path = LaunchConfiguration('model_path', default='/workspaces/isaac_ros-dev/models/dope_soup_60.onnx')
return LaunchDescription([
# Camera input
Node(
package='realsense2_camera',
executable='realsense2_camera_node',
parameters=[{
'rgb_camera.profile': '640x480x30',
'depth_module.profile': '640x480x30',
'enable_depth': True,
'align_depth.enable': True # Align depth to RGB
}]
),
# DOPE inference node (TensorRT-accelerated)
Node(
package='isaac_ros_dope',
executable='dope_decoder',
name='dope',
parameters=[{
'object_name': 'soup_can', # Object class this model detects
'model_file_path': model_path,
'configuration_file': '/workspaces/isaac_ros-dev/config/dope_config.yaml',
# Object dimensions in meters (for PnP)
'object_dimensions': [0.067, 0.067, 0.103], # [width, depth, height]
# Detection threshold
'map_peak_threshold': 0.1
}],
remappings=[
('image', '/camera/color/image_raw'),
('camera_info', '/camera/color/camera_info'),
('dope/pose_array', '/poses') # Output: PoseArray message
]
),
# TF broadcaster to publish object pose in robot frame
Node(
package='isaac_ros_dope',
executable='dope_pose_to_tf',
parameters=[{
'object_frame_id': 'soup_can',
'reference_frame_id': 'camera_color_optical_frame'
}],
remappings=[
('dope/pose_array', '/poses')
]
),
# Visualization
Node(
package='rviz2',
executable='rviz2',
arguments=['-d', './config/dope_visualization.rviz']
)
])
Training DOPE on Custom Objects
To detect your own objects, train DOPE using synthetic data from Isaac Sim:
Step 1: Generate Synthetic Training Data
import omni.replicator.core as rep
from omni.isaac.kit import SimulationApp
simulation_app = SimulationApp({"headless": True})
# Load your custom object (e.g., custom tool)
custom_object = rep.create.from_usd(
"./assets/custom_tool.usd",
semantics=[("class", "custom_tool")]
)
def randomize_scene():
# Randomize object pose
with custom_object:
rep.modify.pose(
position=rep.distribution.uniform((-0.3, -0.3, 0.5), (0.3, 0.3, 0.8)),
rotation=rep.distribution.uniform((0, 0, 0), (360, 360, 360))
)
# Randomize appearance
rep.randomizer.color(
colors=rep.distribution.uniform((0, 0, 0), (1, 1, 1))
)
# Randomize lighting
light = rep.create.light(
light_type="Dome",
intensity=rep.distribution.uniform(500, 2000)
)
return custom_object
rep.randomizer.register(randomize_scene)
# Camera for data capture
camera = rep.create.camera(
position=(1.0, 1.0, 0.6),
look_at=(0, 0, 0.5)
)
# DOPE requires RGB + keypoint annotations
writer = rep.WriterRegistry.get("BasicWriter")
writer.initialize(
output_dir="./dope_training_data",
rgb=True,
bounding_box_2d_tight=True,
bounding_box_3d=True # 3D keypoints for DOPE training
)
writer.attach([camera])
# Generate 10,000 training images
with rep.trigger.on_frame(num_frames=10000):
rep.randomizer.randomize_scene()
rep.orchestrator.run()
simulation_app.close()
Step 2: Train DOPE Model
# Clone DOPE training repository
git clone https://github.com/NVlabs/Deep_Object_Pose.git
cd Deep_Object_Pose
# Prepare dataset (convert Isaac Sim output to DOPE format)
python scripts/prepare_isaac_sim_data.py \
--input_dir ./dope_training_data \
--output_dir ./dope_formatted
# Train DOPE network
python train.py \
--data ./dope_formatted \
--object custom_tool \
--epochs 60 \
--batch_size 32 \
--gpus 1
# Export to ONNX for TensorRT optimization
python export_onnx.py \
--checkpoint ./checkpoints/custom_tool_epoch60.pth \
--output custom_tool.onnx
Depth Perception for Manipulation
Depth sensors provide distance measurements critical for grasp planning.
Integrating Depth with DOPE
import rclpy
from rclpy.node import Node
from geometry_msgs.msg import PoseArray
from sensor_msgs.msg import Image
from cv_bridge import CvBridge
import numpy as np
class DepthEnhancedPose(Node):
def __init__(self):
super().__init__('depth_enhanced_pose')
# Subscribe to DOPE poses
self.pose_sub = self.create_subscription(
PoseArray,
'/poses',
self.pose_callback,
10
)
# Subscribe to depth image
self.depth_sub = self.create_subscription(
Image,
'/camera/aligned_depth_to_color/image_raw',
self.depth_callback,
10
)
self.bridge = CvBridge()
self.latest_depth = None
def depth_callback(self, msg):
# Convert ROS depth image to numpy array
self.latest_depth = self.bridge.imgmsg_to_cv2(msg, desired_encoding='32FC1')
def pose_callback(self, msg):
if self.latest_depth is None:
return
for pose in msg.poses:
# DOPE provides pose estimate, but depth can refine Z coordinate
# Project pose to image coordinates
u, v = self.project_to_image(pose.position)
# Look up depth at that pixel
if 0 <= u < self.latest_depth.shape[1] and 0 <= v < self.latest_depth.shape[0]:
measured_depth = self.latest_depth[v, u]
# Refine pose Z coordinate using depth sensor
refined_z = measured_depth * 0.001 # Convert mm to meters
self.get_logger().info(
f"DOPE Z: {pose.position.z:.3f}m, "
f"Depth Z: {refined_z:.3f}m, "
f"Error: {abs(pose.position.z - refined_z)*1000:.1f}mm"
)
def project_to_image(self, position):
# Camera intrinsics (replace with actual values from camera_info)
fx, fy = 615.0, 615.0 # Focal lengths
cx, cy = 320.0, 240.0 # Principal point
# Project 3D point to 2D image
u = int(fx * position.x / position.z + cx)
v = int(fy * position.y / position.z + cy)
return u, v
def main():
rclpy.init()
node = DepthEnhancedPose()
rclpy.spin(node)
node.destroy_node()
rclpy.shutdown()
if __name__ == '__main__':
main()
Grasp Planning with 6-DOF Poses
Once you have object poses, compute grasp configurations:
import numpy as np
from scipy.spatial.transform import Rotation
def plan_top_down_grasp(object_pose):
"""
Plan a simple top-down grasp for a known object.
Args:
object_pose: geometry_msgs/Pose of the object
Returns:
grasp_pose: Desired end-effector pose for grasping
"""
# Extract object position
obj_pos = np.array([
object_pose.position.x,
object_pose.position.y,
object_pose.position.z
])
# Grasp approach: 10cm above object, gripper pointing down
grasp_offset = np.array([0, 0, 0.10]) # 10cm above
grasp_pos = obj_pos + grasp_offset
# Gripper orientation: Z-axis pointing down
grasp_rot = Rotation.from_euler('xyz', [180, 0, 0], degrees=True)
# Align gripper with object orientation (for non-symmetric objects)
obj_rot = Rotation.from_quat([
object_pose.orientation.x,
object_pose.orientation.y,
object_pose.orientation.z,
object_pose.orientation.w
])
# Combined rotation
final_rot = obj_rot * grasp_rot
return grasp_pos, final_rot.as_quat()
Exercises
-
DOPE Deployment: Run Isaac ROS DOPE with a pre-trained model (soup can or cracker box) and visualize detections in RViz.
-
Depth Fusion: Implement the DepthEnhancedPose node and compare DOPE Z estimates with depth sensor measurements.
-
Custom Object Detection: Choose a household object, generate 1000 synthetic training images in Isaac Sim, and train a DOPE model.
-
Grasp Planning: Given a detected object pose, compute a grasp pose and publish it as a TF frame.
