Week 8: Isaac Sim Fundamentals

Isaac Sim

Introduction to Isaac Sim​

Isaac Sim is NVIDIA's robotics simulation platform built on the Omniverse framework. Unlike traditional simulators, Isaac Sim provides photorealistic rendering using RTX ray tracing, enabling synthetic data generation that closely matches real-world sensor outputs.

Installation and Setup​

System Requirements​

  • GPU: RTX 2060 or higher (8GB+ VRAM recommended)
  • OS: Ubuntu 20.04/22.04 or Windows 10/11
  • RAM: 32GB minimum for complex scenes
  • Storage: 50GB for Isaac Sim + asset libraries

Installation Steps​

# Download NVIDIA Omniverse Launcher
wget https://install.launcher.omniverse.nvidia.com/installers/omniverse-launcher-linux.AppImage

# Make executable and launch
chmod +x omniverse-launcher-linux.AppImage
./omniverse-launcher-linux.AppImage

# From Omniverse Launcher, install:
# 1. Nucleus (local asset server)
# 2. Isaac Sim 2023.1.1 or later

Verifying Installation​

# Test Isaac Sim Python API
from omni.isaac.kit import SimulationApp

# Initialize simulation with specific configuration
simulation_app = SimulationApp({
    "headless": False,  # Set True for server/cloud environments
    "width": 1920,      # Viewport resolution
    "height": 1080
})

from omni.isaac.core import World
from omni.isaac.core.objects import DynamicCuboid

# Create a simple physics test
world = World()
# Add a cube that will fall due to gravity
cube = DynamicCuboid(
    prim_path="/World/Cube",
    position=[0, 0, 2.0],  # 2 meters above ground
    size=0.5,               # 50cm cube
    color=[1.0, 0.0, 0.0]  # Red
)
world.reset()

# Run simulation for 120 frames (2 seconds at 60 FPS)
for i in range(120):
    world.step(render=True)  # Physics step + render

simulation_app.close()

Understanding the Omniverse Foundation​

Universal Scene Description (USD)​

Isaac Sim uses Pixar's USD format as its foundation. USD is a scene description framework that enables:

  • Layered composition - Non-destructive editing by stacking changes
  • Time-sampled data - Animations and dynamic properties stored efficiently
  • Collaboration - Multiple users editing different aspects simultaneously
from pxr import Usd, UsdGeom, Gf

# Create a USD stage (container for 3D content)
stage = Usd.Stage.CreateNew("robot_scene.usd")

# Define a transform (position/rotation in 3D space)
xform = UsdGeom.Xform.Define(stage, "/World/Robot")
xform.AddTranslateOp().Set(Gf.Vec3d(1.0, 0.0, 0.5))  # Position (x, y, z)

# Add a cube mesh representing robot body
cube = UsdGeom.Cube.Define(stage, "/World/Robot/Body")
cube.GetSizeAttr().Set(0.3)  # 30cm cube

# Save the stage to disk
stage.GetRootLayer().Save()
print("USD scene saved to robot_scene.usd")

RTX Ray Tracing for Photorealism​

Isaac Sim leverages NVIDIA RTX GPUs for path-traced rendering, simulating light physics to produce realistic images:

Key Rendering Features​

  1. Global Illumination - Light bounces realistically off surfaces
  2. Reflections and Refractions - Metallic surfaces and glass render accurately
  3. Accurate Shadows - Soft shadows matching real-world lighting conditions
import omni.replicator.core as rep

# Configure RTX ray tracing parameters
rep.settings.set_render_rtx_realtime()  # Real-time RTX mode

# Set samples per pixel (higher = better quality, slower render)
rep.settings.set_rtx_subframes(4)  # 4 samples/pixel balance

# Enable denoising for cleaner output
rep.settings.carb_settings("/rtx/post/dlss/execMode", 1)

Why Photorealism Matters​

For sim-to-real transfer, synthetic training data must match real sensor outputs. RTX rendering produces:

  • Realistic lighting matching warehouse/factory environments
  • Material properties (metal, plastic, fabric) that affect perception
  • Sensor noise simulation for cameras and depth sensors

Creating Your First Simulation​

Loading a Humanoid Robot​

from omni.isaac.kit import SimulationApp
simulation_app = SimulationApp({"headless": False})

from omni.isaac.core import World
from omni.isaac.core.utils.nucleus import get_assets_root_path
from omni.isaac.core.utils.stage import add_reference_to_stage

# Initialize world with physics
world = World(stage_units_in_meters=1.0)

# Get NVIDIA asset server path
assets_root_path = get_assets_root_path()
if assets_root_path is None:
    raise Exception("Could not find Isaac Sim assets folder")

# Load Carter robot (wheeled robot for testing)
robot_usd_path = assets_root_path + "/Isaac/Robots/Carter/carter_v1.usd"
add_reference_to_stage(
    usd_path=robot_usd_path,
    prim_path="/World/Carter"  # Where to place in scene hierarchy
)

world.reset()

# Run interactive simulation (press STOP in UI to exit)
while simulation_app.is_running():
    world.step(render=True)

simulation_app.close()

Exercises​

  1. Scene Construction: Create a USD scene with a ground plane, three colored cubes at different heights, and a directional light source.

  2. Physics Exploration: Modify the cube dropping example to create a Newton's Cradle with 5 spheres. Observe energy conservation in the simulation.

  3. RTX Comparison: Render the same scene with and without RTX enabled. Compare visual quality and rendering time.

  4. Robot Loading: Load the Franka Emika Panda robot from Isaac assets and position it at (0, 0, 1.0).
